The KET-RKP-100 is a magnetic contact for visible installation on non-ferromagnetic and ferromagnetic rack doors. A flat profile of only 5mm makes it suitable for installation on aluminum doors even between the door and doorframe. In this position, moreover, the contact is particularly sensitive, reaching an operating distance of 40mm.
In case of coplanar installation the operating distance is 25 mm. The 3 m cable outlet is available both from the side and from the fixing side.
| Protection Range | IP2 |
| Operative Temperature | -10 ÷ +40 °C |
| Dimensions | 60 x 16 x 5 mm (W x H x D) |
| Mounting | Visible on non-ferromagnetic and ferromagnetic rack doors |
| Material | Black ABS |
| Supply Voltage | 60 VDC @ 500 mA |
| Connectors types | Cable 4 poles black 3 m |
| Referends Standard | EN50131-2-6 |
| Approvals | IMQ |
| Security | Class II |
| Photo | Code | Description |
|---|---|---|
|
KET-RKM-100 |
Smart supervisor for rack Master wireless with LTE modem version |
|
KET-RKS-100 |
Smart supervisor for rack Slave Wireless and ModBUS version |
