Kerberos - Protocol converter for DALI2 controller

Protocol converter for DALI2 controller

KET-RMB-211.CN.DALI is able to manage via RS485 ModBUS the DALI2/ModBUS Slave converter CF.HD67843-B2-Y that can control up to 64 lamps/16 groups with DALI2 protocol.

Radio communication with the RTU with advanced BMS/BEMS functions makes it particularly suitable in a management automation ecosystem.

The device has a format suitable for mounting in a control cabinet on a DIN rail, its antenna connector supports antennas with 90° joint or with cable for positioning outside the control cabinet.

Maximum flexibility of power supply, direct from the mains or low voltage, both DC and AC..

GENERAL SPECIFICATIONS

Protection Range	IP50
Operative Temperature	-20 ÷ +60 °C

CASE

Dimensions	53,5 x 110 x 61 mm (W x H x D)
Mounting	DIN rail or Wall mounting with supplied supports
Required DIN modules	3 DIN modules
Electric Board Type	Industrial or switchboard
Material	Blend PC/ABS sel extinguishing UL94-VO

POWER SUPPLY

Supply Voltage	12 ÷ 24 VDC, 12 ÷ 20 VAC; 230 VAC with integrated power supply
Consumption	< 1.5 W @ 12 ÷ 20 VAC / < 1.5 W @ 12 ÷ 24 VDC / < 1.5 W @ 230 VAC
Connectors types	Screw terminal

RS485 INTERFACE

Supported Protocols	ModBUS RTU Master for managing a single ModBUS/DALI converter CF.HD67843-B2-Y
Connectors types	Screw terminal

RADIO MODULE

Supported Protocols	X-Monitor Protocol (X-MP) / IEEE 802.15.4
Radio Frequency	2.4 GHz ISM Band
Output Power	+3 ÷ +20 dBm
Sensitivity	-104 dBm
Antenna Type	RPSMA connector, 90° antenna supplied
Max Distance (Free Air)	Over 1000 m

FUNCTIONALITY

Radio Signal Indicator	Integrated (LinkQuality)
Output Power Adjustment	From local keyboard and remotely
Firmware Upgrade	Via radio
