Products | KET-TLP-105

Wireless motion, temperature and lighting environmental sensor

KET-TLP-105 is an environmental sensor capable of detecting the movement of people within a radius of about 3-4 meters. The built-in double light sensor allows you to limit the lighting of lights only below a certain lighting threshold that can be set remotely. The temperature sensor completes the characteristics of the device.

The wireless transmission avoids the wiring costs by allowing the sensor to be installed even on the ceiling.

The dry contact input can be used for connecting door / window contacts, PIR sensors or control buttons.

Designed to easily integrate into supervision and energy management systems (BMS / BEMS). Designed for professional use, it supports firmware updating remotely or locally and rapid charging during service. Suitable for use in public environments supports keyboard lock.

GENERAL SPECIFICATIONS
Protection Range IP40
Operative Temperature -10 ÷ +60 °C
Storage Temperature -15 ÷ +60 °C
Relative Humidity MAX 80% not condensing
CASE
Dimensions 100 x 100 x 22.5 mm (W x H x D)
Mounting Wall mounted with supplied plate
Material ABS, self extinguishing: UL 94 V-O
POWER SUPPLY
Supply Voltage 12 VDC
Connectors types Removable spring clamps
DIGITAL INPUTS
Channels 1 for dry contact with detection time at contact variation of about 50ms.
RADIO MODULE
Supported Protocols X-Monitor Protocol (X-MP) / IEEE 802.15.4
Radio Frequency 2.4 GHz
Output Power +3 ÷ +20 dBm
Sensitivity -101 dBm
Antenna Type 1 internal
Max Distance (Free Air) Over 600 m
FUNCTIONALITY
Radio Signal Indicator Integrated (LinkQuality)
Output Power Adjustment From local menu and remotely
Firmware Upgrade via USB C connector
Support for public environment Anti-removal support, keyboard lock
TEMPERATURE SENSOR
Sensor Type NTC or digital (Only .TH version)
Measure Range -40 ÷ +123.8 °C
Precision ±0.4 ÷ 25 °C
Repeatability ±0.1 °C
Resolution ±0.01 °C
HUMIDITY SENSOR
Version Only .TH version
Measure Range 0 ÷ 100%RH
Precision ±3%RH from 20 to 80%RH
Repeatability ±0.1%RH
Resolution ±0.03%RH
Hysteresis ±1%RH
Long Period Stability <0.5%RH/year
LIGHT SENSOR
Number of sensors 2, on front and on top
Measure Range 10 ÷ 1000 Lux
Response Curve Similar to that of the human eye
MOTION SENSOR
Measurand Up to 4 m; Recommended 0 ÷ 3.5 m
Viewing Angle =100° cone angle, distance =4m

Photo Code Description
Power Supply 230 VAC with output 12 VDC / 0.5 A output from junction box
KET-PSA-230.012.005.C

Power Supply 230 VAC with output 12 VDC / 0.5 A output from junction box


Photo Code Description
Advanced X-Monitor gateway with 3G/4G/NB-IoT/LTE-M modem and Wi-Fi™
KET-GZE-310

Advanced X-Monitor gateway with 3G/4G/NB-IoT/LTE-M modem and Wi-Fi™

Master ModBUS RTU Wireless
KET-RMB-211

Master ModBUS RTU Wireless

Climate control interface for Mitsubishi systems
KET-RMB-211.CN.32

Climate control interface for Mitsubishi systems


Photo Code Description
Wireless temperature, relative humidity and light probe
KET-THL-305

Wireless temperature, relative humidity and light probe

Wireless ambient sensor of indirect CO2 and volatile organic compounds
KET-AIR-200

Wireless ambient sensor of indirect CO2 and volatile organic compounds

Wireless motion, temperature and lighting environmental sensor
KET-TLP-105

Wireless motion, temperature and lighting environmental sensor
