The electronic actuator KET-ATW-100 allows to integrate the existing heating bodies in the energy saving system. Acting on the thermostatic valve, the actuator regulates the environmental comfort on the basis of the commands sent by the supervision system.
Its small size allows it to be installed directly on the manifold and inside fan coils and convectors.
Battery power eliminates the need for wiring.
| Protection Range | IP30 |
| Operative Temperature | 0 ÷ +85 °C |
| Storage Temperature | -15 ÷ +60 °C |
| Relative Humidity | MAX 80% not condensing |
| Dimensions | 47 x 91 x 62 mm (W x H x D) |
| Flanged Connections | M30 x 1.5 mm |
| Compatible Valves | IVAR, Caleffi, FAR (with appropriate adapter), Giacomini (with appropriate adapter), IVR. For more compatibility contact the manufacturer. |
| Insulation Class | Class II |
| Supply Voltage | 4.5 V |
| Battery Type | 3 AA |
| Approximate Battery Life | > 3 years |
| Supported Protocols | X-Monitor Protocol (X-MP) / IEEE 802.15.4 |
| Radio Frequency | 2.4 GHz ISM Band |
| Output Power | +3 dBm |
| Sensitivity | -104 dBm |
| Antenna Type | 1 internal |
| Max Distance (Free Air) | Up to 150 m |
| Radio Signal Indicator | Integrated (LinkQuality) |
| Firmware Upgrade | Over The Air |
| Support for public environment | Anti-removal support, keyboard lock |
