ModBUS thermal energy counter in accordance with EN1434

KET-CCC-110 is a calculator with ModBUS RTU interface compatible with all types of flow meters: turbine, Woltmann, ultrasonic and electromagnetic.

The meter calculates heating and cooling consumption extremely accurately, also by means of an automatic switch. It is also useful for cogeneration or trigeneration plants.

It also acquires signals from cold/hot water sanitary meters or in any case traceable to impulsive and/or analogue inputs.

It has an F-RAM type data logger with permanent data storage capacity of up to one year.

Equipped with PT500 temperature probes selected in pairs, for the correct and necessary accuracy of the calculation.

The KET-CCC-110 is approved for "financial transactions" according to EN 1434 as per European Directive 2004/22EG, available in MID version (MI-004).

GENERAL SPECIFICATIONS
Protection Range IP65
Operative Temperature -5 ÷ +55 °C
CASE
Dimensions 125 x 179 x 68 mm (W x H x D)
Mounting DIN-rail
Required DIN modules 6 DIN modules
Electric Board Type Industrial
Material PC/ABS, Self extinguishing
POWER SUPPLY
Supply Voltage 100 ÷ 240 VAC (44-66 Hz)
Consumption 5 W
Connectors types Screw terminal
DATALOGGER FUNCTION
Memory Type F-RAM: permanent storage of data in case of power failure
Data Storage Capacity 12 months
RS485 INTERFACE
Supported Protocols ModBUS RTU
Connectors types Screw terminal
INPUTS
Digital Inputs 1 multifunction (totalizer reset, air conditioning, heating, auxiliary fluid volume)
Analogs Inputs One 4-20 mA input for heat carrier fluid flow measurement
Frequency Inputs 4 inputs (max. frequency 1 kHz, minimum 0.003 Hz): Heat transfer fluid volume, Cold water volume, Hot water volume, Auxiliary fluid volume (or digital input)
Temperature Sensors Inputs 2 (delivery/return)
DIGITAL OUTPUTS
Channels 2 programmable for alarms or pulses for energy/volume
Voltage Output 30 VDC (1250 Hz) @ 100 mA
TEMPERATURE SENSOR
Sensor Type PT500
Measure Range -30 ÷ +200 °C
Precision ±0.2%
Repeatability +0.1%
CERTIFICATIONS
Referends Standard EN1434
