KET-RKE-032 is an industrial extension cord with an integrated single-phase current meter that supports loads up to 32 A.
It is equipped with an RS485 port to connect to other KET-RKE series in daisy-chain (with KET-RKY-101 accessory cable) and to the Rack Monitor KET-RKS or KET-RKM (with KET-RKY-100 accessory cable).
The extension has a total length of 3 m and has a three-pole connector (phase, neutral, ground) that sports 230 VAC @ 32 A.
| Protection Range | Case: IP56; Socket: IP67 |
| Operative Temperature | -25 ÷ +55 °C |
| Storage Temperature | -40 ÷ +70 °C |
| Relative Humidity | MAX 95% not condensing |
| Dimensions | 160 x 115 x 85 mm (W x H x D) |
| Mounting | Wall |
| Material | Thermoplastics |
| Supply Voltage | Self power, 230 VAC (50 Hz) |
| Consumption | <10 VA |
| Connectors types | Industrial extension of 3 m (5 x 6 mm²) with 3-pin connectors (phase, neutral and ground) |
| Supported Protocols | ModBUS RTU |
| Communication Rate | 38400, 19200, 9600, 4800 bps |
| Isolation | Class II |
| Connectors types | 1 RJ45 for connection to other extensions and 1 RJ45 for connection to the rack |
| Voltage Inputs | 230 VAC |
| Current Inputs | 32 A @ 50 Hz |
| Referends Standard | EN50470, IEC61000, EN55022, IEC60068, IEC60529, IEC60695-2-11 |
| Approvals | CE, MID |
| Photo | Code | Description |
|---|---|---|
|
KET-RKY-101 |
RJ45/RJ45 certified UTP 5e cable |
|
KET-RKY-100 |
RJ12/RJ45 certified 5e UTP cable |
| Photo | Code | Description |
|---|---|---|
|
KET-RKM-100 |
Smart supervisor for rack Master wireless with LTE modem version |
|
KET-RKS-100 |
Smart supervisor for rack Slave Wireless and ModBUS version |
| Photo | Code | Description |
|---|---|---|
|
KET-RKE-063.P32S32 |
Industrial extension cord 32 A with ModBUS three-phase power meter |
|
KET-RKE-063 |
Industrial extension cord 63 A with ModBUS three-phase power meter |
|
KET-RKE-032 |
Industrial extension cord 32 A with ModBUS single-phase power meter |
